2020 Southwestern Industries ProtoTrak DPM RX3 Vertical Mill

Stock #1041

Serial # 201EB336

Specifications:

Table Size……………………………………………………   50″ x 10″

T-Slots (number x width x pitch)…………………….. 3 x .63″ x 2.48″

Travel (X, Y, Z axis)………………………………………  31.5″ x 17″ x 25.81″

Quill Diameter………………………………………………              3 15/16″

Maximum Quill Travel……………………………………              5″

Spindle Taper……………………………………………… CAT 40

Spindle Speed Range…………………………………..   40-600, 300-5000

Spindle Center to Column Face………………………   20.5″

Spindle Motor Power……………………………………. 5 HP

Power requirements……………………………………. 200 – 240V; 3P; 35A

Maximum Weight of Workpiece…………………….. 1320 lbs.

Height of table from bottom of bed………………….             36.75″

Max spindle nose to table…………………………….. 25.81″

Min height……………………………………………………              87.5″

Max height………………………………………………….. 96.75″

Width of machine including table…………………….             73.5″

Length with electric box door closed………………. 76.63″

Overall width incl full table traverse…………………             102.25″

Overall length with electrical door open…………..              96.63″

Rapid traverse X, Y, Z…………………………………..  250 IPM on X, Y and Z with Mechanical Handwheels

…………………………………..     400 IPM on X and Y, 250 IPM on Z on EHW machines

Drilling max capacity……………………………………. 1″

Milling max capacity……………………………………. 5 inch³/min

Tapping max capacity………………………………….   1″-8

Footprint of Machine……………………………………. 24″ x 43.31″

Weight ………………………………………………………. 4,100 lbs.

Equipped with:

ProtoTrak RMX CNC Control

Auto Lube Pump

Precision ground ballscrews in the table, saddle and ram

Chrome hardened and ground quill

Meehanite castings

Slide ways are Turcite coated

Wide way surfaces are hardened and ground

Programmable spindle control

Power Drawbar

Work Lamp

Spray Mist Coolant

2 or 3-axis CNC, 3-axis DRO

Real handwheels for manual operation

15.6″ Touchscreen LCD

Intel® 2.0 GHz processor

4 GB Ram

32 GB of mSATA SSD

5 USB connectors

2 Ethernet Ports (1 for user and 1 for motion control)

Override of program Feedrate

Override of spindle speed

LED status lights built into run panel

E-stop

1997 Okuma Cadet Mate Vertical Machining Center

Stock #1031

Specifications:

Table Size……………………………  47.24″ x 20.08″

Table Load Capacity……………… 1500 lbs.

Travel X Axis………………………..  40″

Y Axis…………………………  20″

Z Axis………………………..   20″

Spindle Speed……………………..   40-8000 RPM

Spindle Taper………………………. CAT 40

Approximate Weight…………….. 10,000 lbs.

Approximate Size………………….. 162″ x 135″ x 113″ H

Equipped with:

OSP 700M CNC Control

Machine is in Good Condition. Inspect under Power.

2000 Mazak VTC-200B Vertical Machining Center

Stock #1030

Specifications:

X Axis Travel……………………………………  44″

Y Axis Travel……………………………………  20″

Z Axis Travel……………………………………  20″

Rapid Rate X, Y, Z Axis……………………..   1,181 IPM

Table Size……………………………………….. 57.5″ x 20″

Max Table Load……………………………….. 1,800 LBS

Spindle Motor………………………………….. 20 HP

Spindle Speed…………………………………. 10,000 RPM

Spindle Taper………………………………….. CAT 40

Tool Changer…………………………………… 24 ATC

Max Tool Weight………………………………. 18 lbs.

Max Tool Diameter…………………………… 4.33”

Max Tool Length………………………………. 13.78”

Machine Dimensions…………………………. 118″ x 116″ x 105″

Machine Weight………………………………..  15,000 lbs.

Equipped with:

Fusion 640M CNC Control

ATLM

Chip Conveyor

Machine is in Good Condition. Inspect under Power.

2002 Mazak VTC-160A 2PC Vertical Machining Center with Pallet Changer

Stock #1024

Serial # 156180

Specifications:

Table / Pallet Size…………………………………  16.1” x 25.5”

Number of Pallets…………………………………  2

Travel X-Axis………………………………………     22”

Y-Axis………………………………………      16”

Z-Axis……………………………………..       20”

Spindle Taper…………………………………….     CAT 40

Spindle Speed……………………………………      10,000 RPM

Spindle Motor………………………………………  15 HP

Tool Capacity………………………………………    24 ATC

Machine Dimensions………………………… 84” x 144” x 108” Tall

Machine Weight………………………………….. 17,300 lbs.

Equipped with:

Mazatrol Fusion 640M Control

Factory 2-Pallet Changer

Chip Conveyor

2009 Ibarmia Model ZVH58L4000

Traveling Column 5X Vertical Machining Center

Stock #926

Year: 2009

Manufacturer: Ibarmia

Model: ZVH58L4000 (5-Axis)

Control: Heidenhain iTNC530

X-Axis: 157″

Y-Axis: 39.4″

Z-Axis: 33.9″

Taper: CAT 50

RPM: 6,000

Options: 40 Tools 5 Axis 41″ x 180″ Table 360 PSI CTS

Specifications:

X-axis travel …………………………………… 4000 mm (157”)

Y-axis travel …….……………………………… 1000 mm (39.4”)

Z-axis travel …………………………………….. 860 mm (33.9”)

A-axis travel …………………………………….. +/- 120 degrees

B axis travel ……………………………………… 360 degrees

Rotary table size ……………………………….. 39.4” dia.

Rotary table load capacity ………………….. 5500 lbs.

Fixed Table size ………………………………… 41.3” x 180”

Table load capacity ……………………………. 8000 lbs.

Spindle …………………………………………….. CAT #50

Spindle speed ……………………………………. 6000 rpm

Spindle torque / power ………………………. 260 Ft-lbs / 50 HP cont.

Rapid traverse rates (X, Y & Z) ……………. 1200 IPM

Automatic tool changer capacity ………….. 40 tools

  2003 Okuma Ace Center MB-46VAE Vertical Machining Center

Stock #969

Year: 2003

Manufacturer: Okuma

Model: Ace Center MB-46VAE

Control: OSP E100M

X-Axis: 30″

Y-Axis: 18.11″

Z-Axis: 18.11″

Taper: CAT 40

RPM: 8,000

Options: 20 Tools Chip Conveyor CTS Prepped

Specifications:

Table Working Surface……………………… 39.37″ x 18.11″

Table Load Capacity…………………………  1,540 LBS

Travel X-Axis…………………………………..   30″

Travel Y-Axis…………………………………..  18.11″

Travel Z-Axis…………………………………..  18.11″

Rapid Traverse Rate X&Y Axes)……….. 1575 IPM

Rapid Traverse Rate (Z Axis)…………….. 1181 IPM

Tool Storage Capacity……………………….. 20

Tool to Tool Change Speed………………… 1.2 Sec.

Spindle Horsepower………………………….. 15 HP

Spindle Speeds Range………………………. 50-8,000 RPM

Spindle Taper…………………………………… CAT 40

Machine Dimensions………………………..   106″ x 86″ x 109” Tall

Machine Weight……………………………….. 14,300 LBS

Equipped with:

OSP E100M CNC Control

Chip Conveyor

Coolant thru Prepped – No Pump or Filter

Video link to YouTube of machine running…
